27
AM Tuner
Sensitivity
500
µ V/m
Signal to Noise Ratio
40 dBf
Output level
500 mV
Antenna Input
Loop Antenna
General
Power Consumption:
850 watts
Power Requirements (AC)
115 volts, 60Hz (USA)
230 volts, 50Hz (CE)
Weight
15 Kg/33 lb.
Dimensions (W x H x D)
445 x 160 x 400 mm
17
1/2 " x 6 1/4 " x 15 3/4 "
All specifications are accurate at the time of
printing.
Rotel reserves the right to make improvements
without notice.
Rotel and the Rotel HiFi logo are registered
trademarks of The Rotel Co, Ltd., Tokyo, Japan.
DTS is a registered trademark of Digital Theater
Systems.
Manufactured under license from Dolby Laborato-
ries Licensing Corporation. “Dolby”, “Pro Logic”,
“Dolby Surround”, “Dolby Digital”, and the
double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation. Confidential
unpublished works © 1992 – 1997 Dolby Labora-
tories, Inc. All rights reserved.
Specifications
Audio
Continuous Amplifier Power
(all channels driven)
75 watts/ch (20-20k Hz, <0.09% THD, 8 ohms)
100 watts/ch (1kHz, <1.0% THD, 8 ohms, DIN)
Total Harmonic Distortion
<0.09%
Intermodulation Distortion (60 Hz:7 kHz)
<0.09%
Frequency Response
10 Hz - 20 kHz, ±1 dB (line level)
10 Hz - 20 kHz, ±0.3 dB (digital level)
Signal to Noise Ratio (IHF A-weighted)
92 dB (Stereo) Analog
90 dB (Dolby Digital, dts) 0dBFs
Input Sensitivity/Impedance
Line Level: 200 mV/47 kohms
Tone Controls (Bass/Treble)
±8 dB at 100 Hz/10 kHz
Line Output Level
600 mV (200 mV Input)
Video
Frequency Response
3 Hz-10 MHz, ± 3 dB
Signal to Noise Ratio
45 dB
Input Impedance
75 ohms
Output Impedance
75 ohms
Output Level
1 volt
FM Tuner
Usable Sensitivity
14.2 dBf
Signal to Noise Ratio (at 65 dBf)
70 dBf
Harmonic Distortion (at 65 dBf)
0.03%
Stereo Separation (1 kHz)
45 dB
Output level
1 V
Antenna Input
75 ohms unbalanced
