Runco CR-26HD/CR-32HDi Owner’s Operating Manual

PRE

IMINAR

7.1
Crystal Series LCD
Display Specifications

Table 7-1 lists the Crystal Series LCD Display specifications.

7. Specifications

Table 7-1. Crystal Series LCD Display Specifications

Native Resolution:

1366 x 768 WXGA

Screen Size:

CR-26HD = 26 in. (diagonal)

CR-32HDi = 32 in. (diagonal)

Screen Aspect Ratio:

16:9

Available Aspect Ratios:

4:3, Letterbox, 16:9 Anamorphic, VirtualWide™

DTV Compatibility:

480i/p, 576i/p, 720p, 1080i

ISF Settings:

Yes

Contrast Ratio:

1000:1

Data/Graphics Compatibility:

Up to 1024 x 768

Imagix Processing:

3:2 pull down

Inputs:

Multiple input combinations with up to

(3) Composite, (2) S-Video, (1) Component, (1) DVI
w/HDCP, (1) RGB (15-pin D-sub), (1) RS-232,

(4) Audio (stereo RCA pairs), (1) RF Antenna

Outputs:

(1) Composite, (2) Audio (stereo RCA pair, 3.5-mm stereo
mini jack for headphones)

Audio System:

10W RMS x 2, L/R two-way Integrated Speaker System

Tuner:

NTSC/ATSC Stereo (PAL as monitor only), HDTV Ready,
PIP/PBP, Parental Control (V-Chip), Closed Caption

Discrete IR Control:

Source, power and aspect ratios

Power Requirements:

100 to 240 VAC, 50/60Hz

Power Consumption:

CR-26HD = 130W

CR-32HDi = 180W

Operating Environment:

40ºF to 95ºF (5ºC to 35ºC);

20% to 80% humidity (non-condensing)

Dimensions:

CR-26HD = see Figure 7-1
CR-32HDi = see Figure 7-2

Weight:

CR-26HD = 26.46 lbs. (12 kg)

CR-32HDi = 50.71 lbs. (23 kg)

Regulatory Approvals:

Complies with FCC, UL

Limited Warranty:

One (1) year parts and labor from the date of delivery to the
end user.

Specifications are subject to change without notice.
