Section 1 Configuration

1

UTION

CA

Use an IC149-080-017-B5 socket (manufactured by

YAMAICHI ELECTRONICS Co., Ltd.) for the FP-80A
package IC socket on the user system.

Figure 1 shows the configuration of the HS3864ECH61H user system interface cable for the
FP-80A package.
