Figure 8 installing mcu to user system – Renesas QFP-80A User Manual

Page 17

background image

MCU

Pin 1

IC socket
(IC149-080-017-B5
manufactured by
YAMAICHI ELECTRONICS Co., Ltd.)

User system

Screws (M2 x 8 mm)
with flat washers

Socket cover

Figure 8 Installing MCU to User System

13
