Step 3: Install the Course Computer
Installing the course computer involves these tasks:
Course computer - main parts
3.1 Select the location page 10
3.2 Secure the course computer page 12
3.3 Remove the connector cover page 12
3.4 Attach the power cables page 15
D5413-2
Mounting lug
Keyhole slot
Suppression ferrite
Cables for autopilot
system components
and power
Cable clamp
Tie-wrap
Mounting screws,
No 8 x 3/4 in (x5)
Main cover
Connector
cover
Connector
cover catch
