3. Specifications

Tables 3.1 and 3.2 list specifications of PCA7302E1F-80 and PCA7302E1L-80 respectively.

Table 3.1 Specifications of PCA7302E1F-80

Table 3.2 Specifications of PCA7302E1L-80

PCA7302E1F-80
(Main unit)

PCA7402E
(Connector)

MCU type

Operating clock frequency

Power supply

Board

configuration

Supplied from V

CC

of a PROM programmer

Board to insert a programmable MCU
(IC socket is mounted on this board.)

Board to connect to the PROM programmer
(Standard-pitch 32-pin pin-header is mounted on it.)

IC socket

IC51-0804-819-6 (Yamaichi Electronics Co., Ltd.)

80-pin QFP packages (80P6N-A) of M16C/20 Series
80-pin FP packages

8 MHz
(Supplied by the ceramic oscillator mounted on the adapter)

PCA7412C
(Interface unit)

Interface board
(Connected by two standard-pitch 20-pin connectors and two
standard-pitch 16-pin connectors to the upper and lower boards.)

Type of internal ROM of MCU EPROM

PCA7302E1L-80
(Main unit)

PCA7402E
(Connector)

MCU type

Operating clock frequency

Power supply

Board

configuration

Supplied from V

CC

of a PROM programmer

Board to insert a programmable MCU
(IC socket is mounted on this board.)

Board to connect to the PROM programmer
(Standard-pitch 32-pin pin-header is mounted on it.)

IC socket

IC51-0804-890 (Yamaichi Electronics Co., Ltd.)

80-pin LCC packages (80D0) of M16C/20 Series
80-pin FS packages

8 MHz
(Supplied by the ceramic oscillator mounted on the adapter)

PCA7412C
(Interface unit)

Interface board
(Connected by two standard-pitch 20-pin connectors and two
standard-pitch 16-pin connectors to the upper and lower boards.)

Type of internal ROM of MCU

EPROM

Note:

As this product is designed to support the same packages of M16C/20 Series, it is ready for most of
the products which will be introduced in the future.
