REAR SPEAKER TERMINAL CONNECTIONS

CONNECT AFTER TURNING THE POWER TO THE TV OFF.

Press the Right Speaker button and insert the positive (+) lead wire into the hole next to the button. Once the wire is in place, pull the
red button back to original position and the wire is locked into place. In the same manner, press the Right Speaker black button and
insert the negative (-) lead wire. Repeat this procedure for the Left Speaker.

TO
EXTERNAL
SPEAKER

PROJECTION TV

SPEAKER

AMPLIFIER

CAUTION: Do not connect speakers simultaneously to the REAR SPEAKER terminal of the Projection TV and an

external amplifier. This could damage both the TV and the speakers. your TV was designed to use 8-Ohm
speakers only. Any other type may degrade the audio performance of your entertainment system.

CAUTION: Do not short speaker terminal, (do not connect a wire directly across any two terminals). This could cause

damage to your audio outputs or other damage to your TV.
