FIRST TIME USE
12
ቨ
S-Video Inputs 1 and 2
Inputs 1 and 2 provide S-Video (Super Video) jacks for connecting equipment with S-Video output capability.
ቩ
Component: Y-C
B
C
R
Input 2
Input 2 provides Y-C
B
C
R
jacks for connecting equipment with this capability, such as a DVD player.
NOTES: DO NOT connect standard VIDEO or S-VIDEO to Input 2 when using Y-CBCR input.
When using the Y-CBCR input jacks, connect your components audio output to the TV s Input 2 Left and Right Audio
input jacks.
Your component outputs may be labeled Y, B-Y, and R-Y. In this case, connect the components B-Y output to the TV s
Cb input and the components R-Y output to the TV s CR input.
It may be necessary to adjust TINT or turn AUTO COLOR-ON to obtain optimum picture quality when using the Y-CBCR
inputs. (See pages 53 and 54.)
To ensure no copyright infringement, the MONITOR OUT output will be abnormal, when using the Y-CBCR jacks.
When using the Y-CBCR jacks, Input 2 will be viewed as a blank PIP sub-picture. (See page 27.)
ቪ
Sub Woofer
This jack provides variable audio output to a sub-woofer accessory. With this connection, the audio can be controlled by the
television s main volume and also by an independent sub-woofer volume feature found in the THEATER-SUB WOOFER menu.
