Congratulations on your recent purchase of a Russound CA-Series multi-room controller. This four/six-zone, four-source,
multi-room controller is the heart of an affordable whole-house audio distribution system. High-current, stereo, power
amplifiers are built into the Russound CA allowing simple connections to each speaker in the system. Each zone is operated
by an intuitive, easy-to-use keypad that controls all the functions of the CA. The keypads also have a built-in infrared receiv-
er that allows remote commands for your source equipment to be routed through the CA.
The Russound CA is built with pride. Fidelity, Reliability and Quality are the primary objectives. Russound products are guaran-
teed to provide years of enjoyment. The CA is UL listed and CSA approved for your protection and peace of mind.
POSSIBLE SYSTEM CONFIGURATIONS
P
RODUCT
O
VERVIEW
ZONE 4
Guest Room
ZONE 2
Kitchen
ZONE 3
Master Bedroom
ZONE 1
Living Room
SOURCE EQUIPMENT
Family Room
CASSETTE CD
TUNER
TUNER
CD
CASSETTE
DSS
DSS
(Audio Signal)
CA4.4pi
Controller
ZONE 4
Guest Room
ZONE 2
Kitchen
ZONE 6
Patio
ZONE 3
Master Bedroom
ZONE 5
Childs Room
ZONE 1
Living Room
SOURCE EQUIPMENT
Family Room
CD
CASSETTE
CD
TUNER
TUNER
CD
CASSETTE
DSS
CD
DSS
(Audio Signal) CA6.4
Controller
UNPACKING
Carefully unpack the unit and keep the original carton and
packing materials for future moving, shipment or long-term
storage. After opening the box, please check for any visible
signs of damage that were not apparent from the outside of
the box. If you do encounter what appears to be concealed
damage, please consult your Russound dealer before pro-
ceeding to further unpack or install the unit.
Make sure to save your sales receipt. Your receipt is extreme-
ly important to establish the duration of your limited
Warranty, and for insurance purposes.
Figure 1 - Four-Zones of CA4.4pi
Figure 2 - Six-Zones of CA6.4
