21
Repair Parts
For Repair Parts, Call 1-800-4-RIDGID
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
Ref. Catalog Part
No Number Number Descriptons Qty
1 17993 BG220901AJ Belt guard assembly (includes 38-44) 1
2 17998 ST026200AV Setscrew 1
3 18003 BT023100AV Belt (4L510) 1
4 18008 ST073915AV Filter assembly 1
5 18013 ST073916AV Filter element 1
6 18018 ST070827AV Screw 4
7 —
◆
Nylon tube 1
8 —
◆
Elbow fitting 2
9 17798 V-215106AV ASME Safety valve 1
10 17783 ST071626AV Torx screw 4
11 18028 ST160002AV Handle grip 2
12 17913 D-1403 Drain valve 2
13 17918 ST073612AV Plug 2
14 18033 AR053400OE Tank 1
15 17853 ST158300AV Rubber foot 4
16 18038 ST116400AV Screw 4
17 18043 AA021800AV Axle rod 1
18 18048 ST073613AV Plug 2
19 18053 WA005501AV 10" Pneumatic wheel 1
20 18058 CV006412AV Throttle control 1
21 18063 ST128415AV Throttle unloader 1
22 17878 GA016900AV Gauge, outlet 1
23 17873 HF203300AV Coupler 2
24 17793 WL024501AV Regulator assy. (includes 22, 23 & 25) 1
25 17773 GA016901AV Gauge, tank 1
26 18068 VT471400AJ Pump 1
27 18073 ST186600AV Discharge tube 1
28 18078 PU015900AV Flywheel 1
29 18083 PU015400AV Pulley 1
30 18088 KE000900AV 3/16" Key 1
31 18093 ST012200AV Square head set screw 1
32 18098 BG208800AJ Brace assembly 1
33 18103 NG002502AV Engine 1
34 18108 ST070625AV Hex head screw 4
35 18113 ST011200AV Washer 8
36 18118 AL014000AV Locknut 4
37 18123 ST164100AV Wire retainer 1
38 20978 ST033500AV 3/8” Flange nut 1
39 20983 ST084704AV 3/8” Shoulder bolt 1
40 22788 BG210000AV Beltguard bracket (motor) 1
41 22793 ST070674AV 5/16” - 24 x 1/2” Bolt 1
42 20423 ST016000AV 5/16” - 18 x 3/4” Screw 1
43 18113 ST011200AV 5/16” Washer 1
44 20428 ST146001AV 5/16” - 18 Nut 1
45 21003 BG220400AV Beltguard bracket (pump) 1
46 21008 ST073278AV Beltguard fastener 8
47 22783 ST076829AV M8 - 1.25 x 30 Bolt 1
REPAIR KITS
◆
22098 VT273500AJ Tube kit 1
