M219 room amplifier Re:connect
18
Multiroom cabling
Multiroom cabling uses a CAT 7
cable, in accordance with the
international network standard
EIA/TIA-568-B.
This EIA/TIA-568-B standard
provides for the following
assignment:
The CAT 7 cable is
characterised by 4 twisted pairs,
where each pair has its own
screening. There is a complete
screening around all four pairs.
Personal M219 Settings (DIL switches)
DIL setup switches
Room
1 2 3 4 5 6 7 8
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
Off Off Off Off Off Off Off Off
On On On On On On On On
X X X X X
e.g. Bedroom
X X X
Clamp 1 2 3 4 5 6 7 8
Colour code wh/or or wh/gn bl wh/bl gn wh/bn bn
MR-signal RX TX L+ R+ R- L- GND
MR
GND
