M219 room amplifier
Re:connect
15
[8] IN
RE
V
OX
MR-BUS
Multiroom Bus input
Connection of the
RE
V
OX
Multiroom Bus cable, which is
connected to the Multiroom
central unit e.g. M51 MR
Module MKII.
Connection is made using a
screened and uncrossed
RJ45 cable.
[9] OUT
RE
V
OX
MR-BUS
Multiroom Bus output
Connection for a further M219,
which is connected with a
RE
V
OX
Multiroom Bus cable.
A maximum of 8 M219s can
be connected in this way.
Connection is made using a
screened and uncrossed
RJ45 cable.
[7] CHANNEL
SELECT
Configuration
DIL- 1
Switch
DIL- 2
Switch
DIL- 3
Switch
DIL- 4
Switch
DIL
Position
Operating
mode
Left channel
Right channel
Stereo
On Off Off On
1
4
3
2
Inverse
Stereo
Off On On Off
1
4
3
2
Mono
On On On On
1
4
3
2
You can change the switch settings during operation if the volume
level is turned down low.
