8 9
FEATURES
Fig. 1
PRODUCT SPECIFICATIONS
Length of Stroke.......................................................................................................................................................1-3/16 in.
Strokes Per Minute...............................................................................................................................................0-2500/min.
Motor......................................................................................................................................................................18 Volt DC
Switch........................................................................................................................................... Variable Speed With Brake
Charger Rating ..................................................................................................................................... 120 V, 60 Hz, AC only
Charge Rate .........................................................................................................................................................
30 minutes
KNOW YOUR RECIPROCATING SAW
See Figure 1.
Before attempting to use this product, familiarize yourself
with all operating features and safety rules.
TOOLLESS BLADE CLAMP
Your saw has a blade clamp design that does not require the
use of a tool (blade wrench) when installing or removing the
blade. Simply lift blade clamp lock / release lever, located on
side of saw, insert blade between blade clamp and saw bar
as far as possible, then release lever to lock position.
LOCK-OFF BUTTON
Your saw is equipped with a “lock-off” button which reduces
the possibility of accidental starting. The lock-off button is
located on the handle above the switch trigger. You must
depress the lock-off button to pull the switch trigger. The
lock resets each time the trigger is released. You can depress
the lock-off button from either side.
HEX KEY STORAGE
The hex key storage area is located on the base of the
saw.
SWITCH TRIGGER
The switch trigger is conveniently located on the handle of
the tool.
VARIABLE SPEED
This tool has a variable speed feature that delivers higher
speed with increased trigger pressure.
CHARGER
Your charger has a “key hole” hanging feature for convenient,
space-saving storage. Screws should be installed so that
the center distance is 4-1/8 in.
®
LOCK-OFF
BUTTON
BATTERY
PACK
SWITCH
TRIGGER
BLADE CLAMP
LOCK / RELEASE
LEVER
BASE (SHOE)
ASSEMBLY
SAW
BLADE
4-1/8 in.
CHARGER
HEX KEY
STORAGE
