Flush mounting – Raymarine A60 User Manual
Page 14
14
A60 Installation Manual
5. Use the screws and nuts supplied to securely attach the bracket to the mount-
ing surface.
6. Attach the display unit to the bracket.
7. Adjust the unit angle for clear vision and tighten the knobs.
Flush Mounting
Flush mounting your display on the console requires the optional E36017 Flush
Mount Kit.
1
2
3
D7899-1
x3
x3
D9616-1
87081.book Page 14 Wednesday, December 20, 2006 2:43 PM
