R0E0100TNPFJ00 User’s Manual
7. Precautions and WEEE Directive
CAUTION
Cautions to Be Taken for This Product:
z When connecting the YQPACK100RB, be sure to use the included YQ-GUIDEs.
z Do not use the screws included with the YQPACK100RB for connecting the YQPACK100RB.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z For purchasing the NQPACK100RB, YQPACK100RB, HQPACK100RB168 and HQPACK100RB1622, contact the
following:
Tokyo Eletech Corporation http://www.tetc.co.jp/e_index.htm
Disposal Instruction (This is only valid in the European Union.):
Renesas development tools and products are directly covered by the European Union's Waste Electrical and Electronic
Equipment, (WEEE), Directive 2002/96/EC. As a result, this equipment, including all accessories, must not be disposed
of as household waste but through your locally recognised recycling or disposal schemes. As part of our commitment to
environmental responsibility Renesas also offers to take back the equipment and has implemented a Tools Product
Recycling Program for customers in Europe. This allows you to return equipment to Renesas for disposal through our
approved Producer Compliance Scheme. To register for the program, click here “
http://www.renesas.com/weee " .
8. Correspondence of Connectors CN1 and CN2
Table 2 Correspondence of the connectors
CN1 Pin No. IC1 CN1 Pin No. IC1 CN2 Pin No. IC1 CN2 Pin No. IC1
1 - 100 - 1 - 100 -
2 - 99 - 2 - 99 -
3 - 98 - 3 - 98 -
4 - 97 - 4 - 97 -
5 59 96 58 5 - 96 -
6 60 95 57 6 - 95 -
7 61 94 56 7 - 94 -
8 62 93 55 8 - 93 -
9 63 92 54 9 - 92 -
10 64 91 53 10 - 91 -
11 65 90 52 11 - 90 -
12 66 89 51 12 - 89 -
13 67 88 50 13 - 88 -
14 68 87 49 14 - 87 -
15 - 86 - 15 - 86 -
16 69 85 48 16 - 85 79
17 70 84 47 17 - 84 80
18 71 83 46 18 - 83 81
19 72 82 45 19 - 82 82
20 73 81 44 20 - 81 83
21 74 80 43 21 - 80 84
22 75 79 42 22 - 79 85
23 76 78 41 23 - 78 86
24 77 77 40 24 - 77 87
25 78 76 39 25 - 76 88
26 - 75 - 26 - 75 -
27 99 74 38 27 - 74 89
28 100 73 37 28 -
73 90
29 1 72 36 29 - 72 91
30 2 71 35 30 - 71 92
31 3 70 34 31 - 70 93
32 4 69 33 32 - 69 94
33 5 68 32 33 - 68 95
34 6 67 31 34 - 67 96
35 7 66 30 35 - 66 97
36 8 65 29 36 - 65 98
37 - 64 - 37 - 64 -
38 9 63 28
38 - 63 -
39 10 62 27 39 - 62 -
40 11 61 26 40 - 61 -
41 12 60 25 41 - 60 -
42 13 59 24 42 - 59 -
43 14 58 23 43 - 58 -
44 15 57 22 44 - 57 -
45 16 56 21 45 - 56 -
46 17 55 20 46 - 55 -
47 18 54 19 47 - 54 -
48 - 53 - 48 - 53 -
49 - 52 - 49 - 52 -
50 - 51 - 50 - 51 -
(-:No connection or signals in the emulator)
REJ10J1735-0200 Rev.2.00 Page 3 of 4
Apr 16, 2010
