14

5.4

Dimensions for EV-Chip Board and User System Interface Board

The dimensions for the EV-chip board and the user system interface board are shown in figure 11.

140.0

116.0

Unit: mm
Tolerance: ±0.5 mm

EV-chip board

User system interface board

19.5

31.0

33.5

16.0

100.0

92.0

69.0

29.5

5.0

34.5

Spacer

Figure 11 Dimensions for EV-Chip Board and User System Interface Board
