RF Neulink NL6000 User Guide 10
3. Specifications
GENERAL SPECIFICATIONS
Dimensions 3.0 in L x 2.6 in W x 1.6 in H
DC voltage input Nominal 10-15 VDC
Operating temperature -30° C to +60° C
Number of Channels 64
Number of ID codes 65,525
Over-the-air (Tx) data rate 12,000 bps or 22,050 bps
Serial port baud rates 1200 bps, 2400 bps, 4800 bps,
9600 bps, 19.2 kbps, 28.8 kbps,
38.4 kbps
RF input/output connector SMA-F
Data interface 9-pin (DB9)
Serial interface RS-232 async
Mode of operation Simplex or Half Duplex
Frequency control PLL synthesizer
Error control 3 data transmission modes provide
progressively increasing error correction strength
