Section 1 Configuration
Rev. 2.00 Sep. 08, 2008 Page 2 of 30
REJ10J1868-0200
CAUTION
Use an NQPACK120SE-ND socket and an HQPACK120SE
cover (manufactured by Tokyo Eletech Corporation) for the
PLQP0120LA-A-packaged IC socket on the user system.
Table 1 HS1658RECN61H Components
No. Component Quantity Remarks
1 User system interface
board 1
2 IC socket 1 For the PLQP0120LA-A package (to be mounted on
the user system)
3 Socket cover 1 For installing a PLQP0120LA-A-packaged MCU
4 Screws (M2 x 10 mm) 4 For fastening the board
5 Screws (M2 x 6 mm) 4 For installing a PLQP0120LA-A-packaged MCU
6 Spacers (2.6MP x 25 mm) 2
7 Spacers (2.6MQ x 13 mm) 4
8 Screwdriver 1 For tightening screws
9 Guide pins (
φ1 mm)
3 For determining the IC socket location
10 Documentation 1 User’s manual for HS1658RECN61H (this manual)
