Royal Sovereign 451-8 24B/9L RSL-2702S - Manual (Page 35)

1. Wire Main. 6. Wire Up Heater.
2. Wire Sensor Up 7. Wire Fan(2EA)
3. Wire Sensor Low 8. Wire Power Transformer In
4. Wire Power 9. Motor wires
5. Wire Low Heater 10. Wires Power Transformer Output
33
① ② ③
④
⑤ ⑥
⑦ ⑧
⑨
⑩
