8
FEATURES
PRODUCT SPECIFICATIONS
Chuck ...........................................................1/2 in. Keyless
Motor ..................................................................18 Volt DC
Switch .............................. VSR (Variable Speed Reversible)
No Load Speed ....................... 0-450/0-1,600 r/min. (RPM) Blows per minute ........................... 0-7,200/0-25,600 BPM
Clutch ................................................................ 24 Position
Torque ................................................................... 585 in.lb.
Charger Input ................................... 120 V, 60 Hz, AC only
BIT
STORAGE
DIRECTION OF ROTATION
SELECTOR (FORWARD/REVERSE/
CENTER LOCK)
TORQUE
ADJUSTMENT
RING
KEYLESS
CHUCK
BATTERY
PACK
CHARGER
4-1/8 in.
SWITCH
TRIGGER
FORWARD
REVERSE
AUXILIARY HANDLE
ASSEMBLY
HAMMER MODE
RING
TWO-SPEED
GEAR TRAIN
Fig. 1
CHARGER
