Stereo power amplifier rb-981 – ROTEL RB-981 User Manual
Page 3
Figure 1:
Controls and Connections
Commandes et prises
Bedienelemente und Anschlüsse
Controlli e collegamenti
Controles y Conexiones
POWER
POWER AMPLIFIER RB-981
PROTECTION
BRIDGED MONO
1
2
3
4
LEFT
RIGHT
SPEAKERS
WARNING:
TO REDUCE THE RISK OF FIRE
OR ELECTRICAL SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS:
RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR
SPEAKER IMPEDANCE
STEREO 4 OHMS MINIMUM
BRIDGED 8 OHMS MINIMUM
POWER AMPLIFIER
MODEL NO. RB-981
POWER CONSUMPTION: 400W
SERIAL NO.
LEFT INPUT
RIGHT INPUT
5
5
6
7
STEREO POWER AMPLIFIER RB-981
