Chapter 1: Overview
19
Table 1-9: Max. Extension Power Cable Lengths (m), 24/32 V Systems -
4 kW Scanners
Power Cable Core Size (each core)
mm
2
:
AWG:
2.0
14
4.0
11
6.0
10
8.0
8
10.0
7
4 kW Scanners
8.0
16.0
24
32
35
Table 1-10:Max. Extension Power Cable Lengths (m), 24 V Systems -
10 kW Scanners
Inter-Unit Cable(s)
Power Cable Core (each core)
mm
2
:
AWG:
1.5
16
2.0
15
2.5
14
4.0
11
5 m Heavy
12.0
16.0
20.0
32.0
10 m Heavy
10.5
14.0
18.0
28.0
15 m Heavy
9.0
12.0
16.0
24.0
15 m Heavy + 5 m ext
7.5
10.0
13.0
20.0
15 m Heavy + 10 m ext
6.0
8.0
10.0
16.0
25 m Heavy
6.0
8.0
10.0
16.0
25 m Heavy + 5 m ext
4.5
6.0
8.0
12.0
25 m Heavy + 10 m ext.
3.0
4.0
5.0
8.0
Table 1-11:Max. Extension Power Cable Lengths (m), 32 V Systems -
10 kW Scanners
Power Cable Core Size (each core)
mm
2
:
AWG:
1.5
16
2.0
15
2.5
14
10 kW Scanners
≤≤≤≤
15.0
≤≤≤≤
20.0
≤≤≤≤
25.0
