8
. Precautions
CAUTION
Cautions to Be Taken for This Product:
z Do not solder the M3T-DUMMY80 main unit directly on the target board. Be sure to use the included socket.
z Before mounting the M3T-DUMMY80, be sure to check the pin positions.
z Holder patterns are required at each of the four corners of the target foot pattern. (see Figure 4).
z Be sure to solder the holders of the socket. An insufficient amount of solder applied to the holders may cause a poor
contact, so be careful.
z For soldering the socket and mounting the M3T-DUMMY80, refer to the supplementary document “Mounting the
Socket Included with the M3T-DUMMY80” and “Notes on Handling the M3T-DUMMY80”.
z Do not apply unnecessary stress to the M3T-DUMMY80.
z Do not touch the pins of the M3T-DUMMY80.
z Store the M3T-DUMMY80 in the dedicated case.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z To remove the socket frame, use the dedicated tool AXY8580N1 made by Matsushita Electric Works, Ltd. To
purchase this product and the socket frame for repair, contact Matsushita Electric Works, Ltd.
(http://www.mew.co.jp/e-index.html)
z For onboard evaluation, choose an appropriate socket frame by Matsushita Electric Works, Ltd. listed below.
For 80P6N-A package: Socket frame AXS4802M1 (included)
For 80P6N-C package: Socket frame AXS4802N1 (not included)
z For inquiries about this product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage http://www.renesas.com/en/tools
9. Correspondence of Connectors J1, J2
Table 2 Correspondence of the M3T-DUMMY80 and connectors J1, J2
Pin No.
of
connector
Pin No. of M3T-
DUMMY80
Pin No.
of
connector
Pin No. of M3T-
DUMMY80
Pin No.
of
connector
Pin No. of M3T-
DUMMY80
Pin No.
of
connector
Pin No. of M3T-
DUMMY80
J1-1 65 J1-26 NC J2-1 1 J2-26 25
J1-2 66 J1-27 41 J2-2 2 J2-27 26
J1-3 67 J1-28 42 J2-3 3 J2-28 27
J1-4 68 J1-29 43 J2-4 4 J2-29 28
J1-5 69 J1-30 44 J2-5 5 J2-30 29
J1-6 70 J1-31 45 J2-6 6 J2-31 30
J1-7 71 J1-32 46 J2-7 7 J2-32 31
J1-8 72 J1-33 47 J2-8 8 J2-33 32
J1-9 NC J1-34 48 J2-9 9 J2-34 NC
J1-10 NC J1-35 49 J2-10 10 J2-35 NC
J1-11 NC J1-36 50 J2-11 11 J2-36 NC
J1-12 NC J1-37 51 J2-12 12 J2-37 NC
J1-13 NC J1-38 52 J2-13 13 J2-38 NC
J1-14 NC J1-39 53 J2-14 14 J2-39 NC
J1-15 NC J1-40 54 J2-15 15 J2-40 NC
J1-16 NC J1-41 55 J2-16 16 J2-41 NC
J1-17 NC J1-42 56 J2-17 17 J2-42 NC
J1-18 33 J1-43 57 J2-18 18 J2-43 73
J1-19 34 J1-44 58 J2-19 19 J2-44 74
J1-20 35 J1-45 59 J2-20 20 J2-45 75
J1-21 36 J1-46 60 J2-21 21 J2-46 76
J1-22 37 J1-47 61 J2-22 22 J2-47 77
J1-23 38 J1-48 62 J2-23 23 J2-48 78
J1-24 39 J1-49 63 J2-24 24 J2-49 79
J1-25 40 J1-50 64 J2-25 NC J2-50 80
(NC: No connection)
