(3/4)
5. Connection Procedure (See Figure 3)
The procedure for connecting the M3T-F160-100NSD is shown
below.
(1) Mount the NQPACK100SD-ND on the user system.
(2) Attach the YQPACK100SD on the NQPACK100SD-ND.
(3) Secure the four corners of the YQPACK100SD with the
YQ-GUIDE's.
● Do not use the screws included with the
YQPACK100SD for fixing the YQPACK100SD.
● Do NOT used the screwdriver included with the
NQPACK100SD-ND that is used only for the
HQPACK100SD.
(4) Attach the probe of the emulation pod to the M3T-
F160-100NSD.
(5) Connect M3T-F160-100NSD on the YQPACK100SD.
M3T-F160-100NSD
YQPACK100SD
NQPACK100SD-ND
100-pin 0.5-mm-pitch
(100P6Q-A) foot pattern
(1)
(2)
(3)
(5)
(4)
Use a slotted screwdriver.
YQ-GUIDE (x4)
: No. 1 pin
Be sure to align the pins.
FLX160-PRB
or
M3xxxxTx-EPB
Figure 3 Connection procedure of the M3T-F160-100NSD
6. External Dimensions and a Sample Foot Pattern
55.0 21.8
40
.0
5.
3
0.25
0.5
13.0
17.0
13
.0
17
.0
Unit:mm
16.
5
40
a 40
b
1a 1b
CN2
M
3
T
-F
1
60-
1
00NS
D REV.
A
50
26
25 1
51 75
76
1
00
CN1
M
A
DE
I
N
J
A
P
A
N
40
a 40
b
1a 1b
CN
1
CN
2
Figure 4 External dimensions and a sample foot pattern of the M3T-F160-100NSD
