Renesas PCA7425 - Manual (Page 5)

( 3 / 14 )
Contents
1. Precautions for Safety ......................................................................................................... 4
1.1 Safety Symbols and Meanings .............................................................................. 4
2. Introduction ........................................................................................................................ 6
2.1 Things to Check When Unpacking ....................................................................... 6
3. Specifications ..................................................................................................................... 7
4. How to Write the Program ................................................................................................. 8
4.1 Programming Procedure ........................................................................................ 8
4.2 Attaching the Adapter to a PROM Programmer ................................................... 9
4.3 Inserting an MCU into the Programming Adapter ................................................ 9
4.4 Precautions When Opening and Closing the IC Socket ...................................... 10
4.5 Precautions When Handling the Adapter ............................................................ 10
5. Recommended PROM Programmers ............................................................................... 11
6. How to Request for Support ............................................................................................. 11
To use the product properly
Precautions for Safety:
• Both in this User's manual and on the product itself, several icons are used to insure
proper handling of this product and also to prevent injuries to you or other persons,
or damage to your properties.
• The icons' graphic images and meanings are given in "Chapter 1. Precautions for
Safety" (page 4). Be sure to read this chapter before using the product.
