External dimensions of the m3t-ssop36b-450, Sample foot pattern of the target system – Renesas Dummy IC M3T-SSOP36B-450 User Manual
Page 3

(3/4)
6. External Dimensions of the M3T-SSOP36B-450
Figure 3 External dimensions of the M3T-SSOP36B-450
7. Sample Foot Pattern of the Target System
Figure 4 Dimensions of a target foot pattern (Quoted from the specifications of IC socket for SSOP by Matsushita Electric Works, Ltd.)
M
in
. 1
4
.5
Ma
x
. 9
.0
0.80±0.05
0.20±0.05
13.6±0.1
0.80±0.05
0.4
+0.1
-0
Unit: mm
Upper connector J1:
AXK5S40045P
(made by Matsushita Electric Works, Ltd.)
: Pin No. of the upper connector
: Pin No. of the M3T-SSOP36B-450
1
D
E
36
19
18
21
20
b
e
HD
Material:
Glass epoxy board
Board
Upper connector
(J1)
Material:
Heat tolerant resin (body)
Copper alloy (post, contact)
Plating:
Nickel-based gold plating
Material:
Bronze phosphide
Plating:
Solder plating
Pin
A
Symbol
b
D
E
e
HD
0.3
0.8
12.4
15.0
8.4
4.2
Dimension (mm)
J
1
40
1
21
20
1
A
1
1
40
