R0E530650CFK10 User’s

Manual

7. Precautions and WEEE Directive

CAUTION

Cautions to Be Taken for This Product:

z When connecting the YQPACK128RD, be sure to use the included YQ-GUIDEs.
z Do not use the screws included with the YQPACK128RD for connecting the YQPACK128RD.

IMPORTANT

Notes on This Product:

z We cannot accept any request for repair.
z For purchasing the NQPACK128RD, YQPACK128RD and HQPACK128RD, contact the following:

Tokyo Eletech Corporation

http://www.tetc.co.jp/e_index.htm

Disposal Instruction (This is only valid in the European Union.):

Renesas development tools and products are directly covered by the European Union's Waste Electrical and Electronic
Equipment, (WEEE), Directive 2002/96/EC. As a result, this equipment, including all accessories, must not be disposed
of as household waste but through your locally recognised recycling or disposal schemes. As part of our commitment to
environmental responsibility Renesas also offers to take back the equipment and has implemented a Tools Product
Recycling Program for customers in Europe. This allows you to return equipment to Renesas for disposal through our
approved Producer Compliance Scheme. To register for the program, click here “

http://www.renesas.com/weee

"

.

8. Correspondence of Connectors CN1 and CN2


Table 2 Correspondence of the connectors

CN1 Pin No.

IC1

CN1 Pin No.

IC1

CN2 Pin No.

IC1

CN2 Pin No.

IC1

1 - 100

- 1 - 100

-

2 - 99 - 2 - 99 -
3 - 98 - 3 - 98 -
4 - 97 - 4 - 97 -
5 77 96 76 5 57 96 -
6 78 95 75 6 56 95 -
7 79 94 74 7 55 94 62
8 85 93 73 8 54 93 63
9 86 92 72 9 49 92 64

10 87 91 71 10 48 91 80
11 88 90 70 11 47 90 81
12 89 89 69 12 46 89 82
13 90 88 68 13 - 88 83
14 91 87 67 14 - 87 84
15 - 86 - 15 - 86 -
16 92 85 66 16 - 85 102
17 93 84 65 17 - 84 103
18 94 83 61 18 - 83 104
19 95 82 60 19 - 82 105
20 96 81 59 20 - 81 106
21 97 80 58 21 - 80 107
22 98 79 53 22 - 79 108
23 99 78 52 23 - 78 109
24 100 77 51 24 -

77 110

25 101 76 50 25 -

76 111

26 - 75 - 26 - 75 -
27 2 74 45

27 - 74

120

28 3 73 44

28 - 73

121

29 4 72 43

29 - 72

122

30 5 71 42

30 - 71

123

31 6 70 41

31 - 70

124

32 7 69 40

32 - 69

125

33 8 68 38

33 - 68

126

34 9 67 36

34 - 67

127

35 10 66 35 35 - 66 128
36 13 65 34 36 - 65 1
37 - 64 - 37 - 64 -
38 14 63 33 38 - 63 112
39 15 62 32 39 - 62 113
40 16 61 31 40 - 61 114
41 17 60 30 41 - 60 115
42 18 59 29 42 - 59 116
43 19 58 28 43 - 58 117
44 20 57 27 44 - 57 118
45 21 56 26 45 - 56 119
46 22 55 25 46 12 55 -
47 23 54 24 47 11 54 -
48 - 53 - 48 - 53 -
49 - 52 - 49 - 52 -
50 - 51 - 50 - 51 -

(-:No connection or signals in the emulator)
