Chapter 2.Purpose
This RSK Application Board is an evaluation tool for Renesas microcontrollers with an LCD driver interface. It is used in conjunction with
the RSK for the microcontroller to be evaluated.
Features include:
• Mounting connections to allow RSK to be added to top of board.
• Interface to standard RSK LCD expansion connector and RSK expansion connections.
• 8 character 14 segment “starburst” LCD.
• Coin cell holder to power mounted RSK for low power operation.
4
