Electrical characteristics (cont.) – Renesas M52757FP User Manual
Page 5
M52757FP
REJ03F0195-0201 Rev.2.01 Mar 31, 2008
Page 5 of 6
Electrical Characteristics (cont.)
Limits
Item Symbol
Min
Typ
Max
Unit
Test
Point (s)
Input
SW18
Min. detectable Sync amplitude SDETrv 0.2
V
P-P
14 3,
9
Max. detectable Sync width
SDETrt
4.0
µs 14 3,
9
Sync-DET output high level
SDVH
4.5
4.9
V 14
3,
9
Sync-DET output low level
SDVL
0.2
0.4
V
14
3,
9
Max. allowable input noise level
SDETnv
0.05
V
P-P
14 3,
9
Allowable input DC range
VDinV
2.0
2.4
2.8
V
19, 21, 23
19, 21, 23
Allowable input amplitude range
VDin
0.7
1.0
V
P-P
19, 21, 23
19, 21, 23
Min. detectable input level
VDETrv
0.15
V
P-P
17
19, 21, 23
Max. allowable input noise level
VDETnv
0.1
V
P-P
17
19, 21, 23
Max. input pulse width
VDETrt
10.0
ns
17
19, 21, 23
Video-DET output Hi level
SDVH
4.2
4.8
V
17
19, 21, 23
Video-DET output Low level
SDVL
0.7
1.0
V
17
19, 21, 23
