M52757FP
REJ03F0195-0201 Rev.2.01 Mar 31, 2008
Page 4 of 6
Electrical Characteristics
(V
CC
= 5 V, Ta = 25
°C)
Limits
Item Symbol Min Typ Max Unit
Test
Point (s) Input SW18
Circuit current 1 I
CC
1 45 65 85 mA A
 OPN
Circuit current 2 I
CC
5 3 5 7 mA 15
 OPN
Output DC voltage 1 Vdc1 1.1 1.5 1.9 V 29, 32, 35
 OPN
Output DC voltage 2 Vdc2 1.1 1.5 1.9 V 29, 32, 35
 GND
Output DC voltage 3 Vdc3 0.5 0.9 1.3 V 27
 OPN
Output DC voltage 4 Vdc4 0.5 0.9 1.3 V 27
 GND
Maximum allowable input 1 VImax1 1.4 1.6

V
P-P
1, 3, 5 1, 3, 5 GND
Maximum allowable input 2 VImax2 1.4 1.6

V
P-P
7, 9, 11 7, 9, 11 GND
Voltage gain 1 Gv1
−0.1
0.5 1.1 dB 29, 32, 35 1, 3, 5 GND
Relative voltage gain 1
∆Gv1 −0.6
0 0.6 dB Relative to measured values above
Voltage gain 2 Gv2
−0.1
0.5 1.1 dB 29, 32, 35 7, 9, 11 OPN
Relative voltage gain 2
∆Gv2 −0.6
0 0.6 dB Relative to measured values above
Voltage gain 3 Gv3
−0.6
0 0.6 dB 27 3 GND
Voltage gain 4 Gv4
−0.6
0 0.6 dB 27 9 OPN
Freq. characteristic 1 (100 MHz) Fc1
−1.0
0 1.0 dB 29, 32, 35 1, 3, 5 GND
Relative Freq. characteristic 1
∆Fc1 −1.0
0 1.0 dB Relative to measured values above
Freq. characteristic 2 (100 MHz) Fc2
−1.0
0 1.0 dB 29, 32, 35 7, 9, 11 OPN
Relative Freq. characteristic 2
∆Fc2 −1.0
0 1.0 dB Relative to measured values above
Freq. characteristic 1 (250 MHz) Fc3
−3.0 −1.5
1.0 dB 29, 32, 35 1, 3, 5 GND
Freq. characteristic 2 (250 MHz) Fc4
−3.0 −1.5
1.0 dB 29, 32, 35 7, 9, 11 OPN
Crosstalk between 2 inputs 1
(10 MHz) CTI1
 −60 −50
dB 29, 32, 35 1, 3, 5 GD to OP
Crosstalk between 2 inputs 2
(10 MHz) CTI2
 −60 −50
dB 29, 32, 35 7, 9, 11 OP to GD
Crosstalk between 2 inputs 3
(100 MHz) CTI3
 −40 −35
dB 29, 32, 35 1, 3, 5 GD to OP
Crosstalk between 2 inputs 4
(100 MHz) CTI4
 −40 −35
dB 29, 32, 35 7, 9, 11 OP to GD
Crosstalk between channel 1
(10 MHz) CTC1
 −50 −40
dB 29, 32, 35 1, 3, 5 GND
Crosstalk between channel 2
(10 MHz) CTC2
 −50 −40
dB 29, 32, 35 7, 9, 11 OPN
Crosstalk between channel 3
(100 MHz) CTC3
 −30 −25
dB 29, 32, 35 1, 3, 5 GND
Crosstalk between channel 4
(100 MHz) CTC4
 −30 −25
dB 29, 32, 35 7, 9, 11 OPN
Tr1

1.6 2.5 ns 29, 32, 35 1, 3, 5 GND Pulse characteristic 1
Tf1

1.6 2.5 ns 29, 32, 35 1, 3, 5 GND
Tr2

1.6 2.5 ns 29, 32, 35 7, 9, 11 OPN Pulse characteristic 2
Tf2

1.6 2.5 ns 29, 32, 35 7, 9, 11 OPN
Sync input min. level SYrv 0.2
 
V
P-P
25 26

Sync-sep output Hi level SYVH 4.5 4.9
 V 25
26

Sync-sep output Low level SYVL
 0.2
0.4 V 25 26

Sync-sep output delay time 1 TdSf
 60  ns 25
26

Sync-sep output delay time 2 TdSb
 60  ns 25
26

