10
o
Ptional
c
leaning
t
oolS
All Riccar upright vacuum cleaners offer an attachment port
that enables you to insert optional cleaning tools (available
through your Riccar dealer). Should you have carpeted
stairs, for example, it is highly recommended to use one of
the two kits pictured, since each offers either a 12- or 15- foot
hose for safe stair cleaning. These kits are effective overall
cleaning tools to address some of the hard to reach areas of
your home or car. Talk to your Riccar dealer to see which
tools might be beneficial to your home environment.
For Models Without On-Board Tools
Deluxe Attachment Set DLATT12G (Fig. 32)
1. 12-foot hose
2. Curved wand
3. Extension wand (2 pieces)
4. Dusting brush
5. Crevice tool
6. Upholstery tool
7. Upholstery brush insert
8. Deluxe floor brush
For Models With On-Board Tools
Attachment Set DLATT15 (Fig. 33)
1. 15-foot hose
2. Curved wand
3. Deluxe floor brush
1. How to connect the hose assembly to the vacuum
cleaner: Pull out and open the suction control dial by
turning the lid located on the back of the vacuum
cleaner. Insert the soft, rubber end of the hose assem-
bly into the cleaning attachment opening. Push in
while twisting the hose end to ensure the hose is
fastened securely (Fig. 34).
2. How to connect the tool: You can connect any of the
cleaning tools to the end of the extension wand(s) or
curved wand and twist for a secure fit. To remove the
cleaning tool from the extension wand(s) or curved
wand, simply twist and pull apart.
WarnInG: If optional tools are used do not keep unit
running in one spot for a long period to prevent carpet
damage.
Fig. 33
Fig. 34
Fig. 32
