FAST TASK™ CLEANING TOOLS
(Models 100, 300, and 300C)
Select models are equipped with Fast Task™ cleaning tools which
include a combination upholstery/dusting tool, crevice tool, and
stretch hose.
1. Remove the telescopic wand from the body of the vacuum
[Fig. 27]. Unlock wand collar (located on end of wand)
[Fig. 28], extend wand, and re-lock the wand collar.
NOTE: Wand collar locking rotation is marked with arrows on
wand. Wand collar lock and unlock functions require only 1/2 turn
of collar.
2. Remove the crevice tool on left side of vacuum cleaner and
insert into end of wand [Fig. 29]. The vacuum is now ready
for crevice cleaning.
3. Insert the combination upholstery/dusting tool (located
conveniently in the back of the dust compartment) onto the
end of the crevice tool [Fig. 30]. The combination tool can also
be inserted directly onto the telescopic wand. To convert the
dusting brush to an upholstery tool, simply slide the brush
off [Fig. 31].
9
t
oolS
f
ull
b
ag
i
ndicator
l
ight
Fig. 30
Fig. 27 Fig. 29
Fig. 28
Fig. 31
MODELS 300 and 300C
The warning light is located on top of the dust compartment
(see Fig. 26). The light will trigger if the filter bag is full or
if there is a clog in the vacuum cleaner. If the light indica-
tor turns on, check the filter bag. If it is not full, check the
vacuum cleaner for clogs by inspecting the agitator area
(see “How to Remove the Bottom Plate”), hose, and/or
attachment inlet.
Please disregard the indicator light during attachment
cleaning. The light is designed to indicate air flow restric-
tion during carpet cleaning. When using cleaning attach-
ments, the indicator will light periodically due to normal
attachment air flow restrictions.
Fig. 26
