Specifications
D-BASS 210 D-BASS 115
Rated Power Output 400 W (Woofer 160 W x 2 + Tweeter 80 W) 330 W (Woofer 250 W + Tweeter 80 W)
Nominal Input Level
INPUT PIEZO: -13 dBu/4.7 M Ω
INPUT NORMAL: -10 dBu/1 M Ω (PICKUP TYPE: PASSIVE)
0 dBu/50 k Ω (PICKUP TYPE: ACTIVE)
EFFECT RETURN: +4 dBu
Nominal Output Level
SUB OUT: +4 dBu
LINE OUT: +4 dBu
EFFECT SEND: +4 dBu
TUNER OUT: -10 dBu
BALANCED OUT: +4 dBu
Speaker 25 cm (10 inches) x 2 + Tweeter 38 cm (15 inches) x 1 + Tweeter
Controls
POWER Switch, VOLUME Knob, MUTE Switch
PICKUP TYPE Switch (ACTIVE, PASSIVE), GAIN Knob
AMP TYPE Knob (SUPER FLAT, VINTAGE, MODERN), SHAPE Switch
MODE Switch (TUBE LOGIC, STANDARD), COMPRESSION Knob
BASS Knob, MIDDLE Knob, FREQUENCY Knob, TREBLE Knob, TWEETER Knob
EFFECT BLEND Knob
SELECT Switch (DI OUT, LINE OUT), GND LIFT Switch (ON, OFF)
Indicators POWER, PEAK, MUTE
Connectors
PIEZO INPUT Jack (1/4” phone type)
NORMAL INPUT Jack (1/4” phone type)
PHONES Jack (Stereo 1/4” phone type)
FOOT SW (MUTE) Jack (1/4” phone type)
SUB OUT Jack (1/4” phone type)
LINE OUT Jack (1/4” phone type)
EFFECT Jacks (SEND/RETURN) (1/4” phone type)
TUNER OUT Jack (1/4” phone type)
BALANCED OUT Connector (XLR type)
Power Supply AC115V, AC 117 V, AC 220V, AC 230 V, AC 240 V (50/60 Hz)
Power Consumption 95 W 92 W
Dimensions
(Excluding casters)
595 (W) x 410 (D) x 574 (H) mm
23-7/16 (W) x 16-3/16 (D) x 22-5/8 (H) inches
(Including casters)
595 (W) x 410 (D) x 625 (H) mm
23-7/16 (W) x 16-3/16 (D) x 24-5/8 (H) inches
(Excluding casters)
595 (W) x 410 (D) x 623 (H) mm
23-7/16 (W) x 16-3/16 (D) x 24-9/16 (H) inches
(Including casters)
595 (W) x 410 (D) x 674 (H) mm
23-7/16 (W) x 16-3/16 (D) x 26-9/16 (H) inches
Weights 24.0 kg / 52 lbs 15 oz 23.5 kg / 51 lbs 13 oz
Accessories Owner’s Manual, Information sheet, Caster x 4
Options Foot Switch FS-5L (BOSS)
210/115
