23
Troubleshooting
* 0 dBu = 0.775 Vrms
In the interest of product improvement, the specifications and/or appearance of this unit
are subject to change without prior notice.
D-BASS 115X
Rated Power Output 330 W (Woofer 250 W + Tweeter 80 W)
Nominal Input Level INPUT: +4 dBu/22 k Ω
Nominal Output Level THRU OUT: +4 dBu
Speaker 38 cm (15 inches) x 1 + Tweeter
Controls
POWER Switch, VOLUME Knob,
MODE SELECT Switch (FULL RANGE, SUB WOOFER)
TWEETER Knob
FREQUENCY Knob
Indicators FULL RANGE, SUB WOOFER
Connectors
INPUT Jack (1/4” phone type)
THRU OUT Jack (1/4” phone type)
Power Supply AC115V, AC 117 V, AC 220V, AC 230 V, AC 240 V (50/60 Hz)
Power Consumption 92 W
Dimensions
(Excluding casters)
595 (W) x 517 (D) x 530 (H) mm
23-7/16 (W) x 20-3/8 (D) x 20-7/8 (H) inches
(Including casters)
595 (W) x 517 (D) x 581 (H) mm
23-7/16 (W) x 20-3/8 (D) x 22-7/8 (H) inches
Weights 27.0 kg / 59 lbs 9 oz
Accessories Owner’s Manual, Information sheet, Caster x 4
Troubleshooting
Sounds not output
❑ Is the mute function switched on?
→ If you have a foot switch connected, set both the foot switch and the front panel MUTE switch to OFF.
❑ Is the power to the external effects processor turned off or the effect volume turned completely down?
→ With an external effects processor connected, and using a series connection, only the effect sound is output (p. 12). Check the
external effects processor’s output level.
D-BASS 115X TWEETER LEVEL knob has no effect
❑ Is the TWEETER knob on the D-BASS 210/115 connected to the INPUT jack turned completely down?
→ When the TWEETER knob on the D-BASS 210/115 is turned down all the way, the signals in the tweeter’s frequency range
are not output from SUB OUT, diminishing the effect of the 115X’s TWEETER knob.
210/115
115X
