Please refer to the illustration in section
E of the illustration sheet, and your HumidAire 3i
manual.
The
H
UMID
A
IRE
3i
attaches to the front of the
S8 E
SCAPE
to provide heated
humidification. No other accessories are required for its use
.
Notes:
a. Make sure the water chamber of the HumidAire 3i is empty before you attach or
detach the humidifier.
b. Remove the connector plug on the S8 Escape (see section
A of the illustrations
sheet) before you attach the HumidAire 3i. Reattach the connector plug firmly
after you detach the HumidAire 3i.
S
TORING
THE
H
UMID
A
IRE
3
i
Store the
H
UMID
A
IRE
3i
in the larger mesh-top pouch of the
S8 E
SCAPE
carry bag when
not in use.
A
TTACH
A
H
UMID
A
IRE
H
UMIDIFIER
Please refer to the illustrations in section
I of the illustration sheet.
To connect your
S8 E
SCAPE
to a
H
UMID
A
IRE
humidifier you need medium sized
(52 cm) air tubing.
1
Fill the
H
UMID
A
IRE
water chamber and place inside the
H
UMID
A
IRE
. Connect the
medium (52 cm) and long (2 m) air tubing (
I-1), and close the humidifier lid.
2
Place the
S8 E
SCAPE
on top of the
H
UMID
A
IRE
(
I-2) and connect the free end of the
medium air tubing to the air outlet (
I-3).
Note: To avoid water spilling into the S8 Escape, do not put it underneath the humidifier.
3
Assemble your mask system and connect it to the free end of the long air tubing (
I-4).
4
Plug the
H
UMID
A
IRE
power cord into a power outlet. Connect the
S8 E
SCAPE
power
cord to the socket at the rear of the
S8 E
SCAPE
and plug the other end into a power
outlet.
Please refer to the HumidAire User’s Manual for further details.
!
WARNING
Make sure that the power cord and plug are in good condition and the equipment
is not damaged.
The
S8 E
SCAPE
is now ready for use with the
H
UMID
A
IRE
.
