33 Runco CL-810 Owner’s Operating Manual
➤
Filter The Filter setting controls the behavior of the Sharpness control. The available
settings depend on the vertical resolution of the input signal, as follows:
• With a 480i signal, you can apply the sharpness control to either the input signal
(1), the output signal (2), both (3) or neither (0).
• With a 480p or higher-resolution signal, the sharpness control is applied only
to the output signal and only when you set the Sharpness filter to “on” (1).
The CL-810 has six memory settings for Color Temperature. Four of these settings
are factory set to default as follows:
0 -- Original lamp color temperature
1 -- 5400 kelvins
2 -- 6500 kelvins
3 -- 8500 kelvins
4 -- Custom
5 -- Custom
Custom 4 and 5 memory are installer-adjustable and can be used to create custom
settings. There are nine adjustable “white balance” parameters available for the Custom
4 and 5 settings (three each for red, green and blue). These are described later in this
section; refer to “Set Up.”
NOTE: You must enter a passcode in order to enter the Set Up menu.
Use the ICC Selection menu to select the color space that is appropriate for the
source signal, to achieve optimal color balance.
NOTE: The International Color Consortium (ICC) is a group of imaging product vendors
that promotes and develops cross-platform, vendor-neutral color measurement and
management standards.
If you select NTSC, HDTV or PAL, you can make further adjustments to individual
color space characteristics in the
ICC Adjust sub-menu under the ISF Calibration
menu, described later in this section. (The Standard color space is factory-set and
not adjustable.)
Once the desired adjustments have been entered, select
Store Image Settings to
save these settings into the “Memory 1” memory location.
To recall stored custom image quality settings, select Restore Image Settings and
choose “Memory 1,” “ISF Night” or “ISF Day.”
➤
Color Temperature
Color Temperature
2 - +
On-Screen Display Menus
➤
Store Image Settings
➤
Restore Image Settings
➤
ICC Selection
