Ridge Tool Company 3
Model RT-175 Electric Soldering Gun
OFF. Any tool that cannot be controlled with the
switch is dangerous and must be repaired.
• Store idle tools out of the reach of children and
other untrained persons. Tools are dangerous in
the hands of untrained users.
• Maintain tools with care. Properly maintained tools
are less likely to cause injury.
• Check for breakage of parts and any other condi-
tion that may affect the tool’s operation. If dam-
aged, have the tool serviced before using. Many
accidents are caused by poorly maintained tools.
• Use only accessories that are recommended by
the manufacturer for your model. Accessories that
may be suitable for one tool may become hazardous
when used on another tool.
• Inspect tool and extension cords periodically and
replace if damaged. Damaged cords increase the risk
of electrical shock.
• Keep handles dry and clean; free from oil and
grease. Allows for better control of the tool.
• Check electrodes for wear and replace before the
threaded studs show. Prevents electrical arcing and
excessive current draw.
Service
• Tool service must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified repair personnel could result in injury.
• When servicing a tool, use only identical replace-
ment parts. Follow instructions in the Maintenance
Section of this manual. Use of unauthorized parts or
failure to follow Maintenance Instructions may create a
risk of electrical shock or injury.
• Disconnect all power from the unit before servic-
ing. Eliminates the risk of electrical shock and acci-
dental starting.
Specific Safety Information
WARNING
Read this operator’s manual carefully before using
the Electric Soldering Gun. Failure to understand
and follow the contents of this manual may result
in electrical shock, fire and/or serious personal
injury.
Call the Ridge Tool Company, Technical Service De-
partment at (800) 519-3456 if you have any questions.
Tool Safety
• Tool is made to solder copper pipe. Follow instruc-
tions on proper use. Other uses may increase the risk
of injury.
• Do not leave the unit unattended. Such preventive
measures reduce the risk of injury or fire.
• Do not touch solder gun sleeves or carbon tips.
They remain hot after use.
• Do not operate unit with the electrical box cover
removed. Exposure to internal parts increases the
risk of electrical shock.
• Use soldering sleeves and carbon tips provided
with unit. Incorrect carbon tips or sleeves may result
in overheating of the wires.
• Keep soldering sleeves away from combustible
materials or articles that can be damaged by
heat. Soldering sleeves and carbon tips remain hot
after use.
• Do not solder near combustible materials. Copper
pipe and soldering sleeves reach temperatures that
can result in fire.
• Do not store the handle in the case until the carbon
tips have cooled. They may burn the cord or solder
gun cable.
• Do not clamp or touch threaded studs or stainless
steel sleeves against pipe or fittings. Prevents elec-
trical arcing and excessive current draw that may kick
out circuit breaker.
Description, Specifications and
Standard Equipment
Description
The RT-175 Electric Soldering Gun is capable of solder-
ing joints in copper tube up to 3
″
diameter while using a
standard 110V, 15A circuit. The soldering gun will heat
copper to temperatures in excess of 750°F which allows
it to successfully melt solders used in plumbing applica-
tions – from the 50/50 solders to the 95/5 lead-free types.
Specifications
Power Input ...................115 V, 15 A
Power Output ................(open circuit voltage)
Hi = 7.0 V, Low = 6.2 V
Current Draw .................13.5A @ Low Setting
15.0A @ High Setting
