5228 Double Insulated Variable Speed, Dual Action Reciprocating Saw
Ridge Tool Company 4
Specifications
Maximum Material Thickness
Metal Cutting ............. 3 /
4
″
Wood Cutting ............12 ″
Blade Stroke..................1 1 /
8
″
Motor
Type ..........................Universal
Rating ........................115V, 25-60Hz., AC/DC
9.6A, 0-2600 Strokes/Min.
Switch
OFF/ON.....................Spring-return type
High Speed/
Low Speed ................Manual position
Length ...........................17 ″
Weight ...........................9.0 Lbs.
Accessories
Carbon Steel
Saw Blade .................(1) D-999 6TPI
Blade Wrench............ 3 /
16
″
(Hex Key Type)
Operating Instructions
WARNING
Before attempting to use this tool, read complete
operating instructions to become familiar with all
functions. As this tool was designed for specific ap-
plications, we strongly recommend that it NOT
be modified and/or used for any application other
than for which it was designed.
Blade Selection
A wide assortment of RIDGID blades is listed in the
RIDGID catalog. For maximum efficiency, long blade
life and smooth cutting, select the proper blade for work
being done. When cutting metal, always select blade
which will allow at least three teeth to be in contact with
the thickness of the material.
Blade Installation
No. 5228 Type II
The reciprocating shaft must be fully extended to permit
access to the blade release collar. If necessary, gently
squeeze the trigger switch to move the reciprocating
shaft to its outermost position. Pivot the guide shoe
FORWARD to improve access to the blade clamp.
Tool Safety
• Do not alter or misuse tool. Other uses may in-
crease the risk of injury.
• Position electric cord clear of saw blade. Damaged
cord can cause electrical shock.
• Do not reach across the saw or wear loose cloth
gloves. May become entangled in the tool causing
serious injury.
• Do not use dull or damaged saw blades. Less likely
to bind and lose control.
• Keep fingers and hands away from the saw blade.
Reduces the risk of being cut.
• Keep hands and feet clear of work pieces that may
fall after being cut. Reduces the risk of injury.
• Always use the blade recommended for the mate-
rial being cut. Less likely to bind and lose control.
• Always hold saw as shown in Figure 4. Have the
rubber front housing cover properly installed and
not damaged. Prevents electrical shock resulting
from cutting a live wire when sawing into a wall or other
blind area.
• Do not operate with guide shoe removed. Can result
in blade breakage or losing control of the tool.
• Some wood contains preservatives which can be
toxic. Take extra care to prevent inhalation and skin
contact when working with these materials. Request,
and follow, any safety information available from your
material supplier.
SAVE THESE INSTRUCTIONS!
Description, Specifications and
Accessories
Description
The RIDGID No. 5228 Double Insulated Variable Speed,
Dual Action Reciprocating Saw is a professional quality,
extra heavy duty tool. This saw operates at variable
speeds and features a dual blade motion for efficient cut-
ting of wood or metal. It is designed for cutting wood up to
12 inches thick, metal up to
3 /
4
inches thick and various
other materials including hard rubber, laminates, fiber-
glass and plastics. The motor will operate on single-phase
25 to 60 Hertz AC current with voltage within plus or
minus 5% of that shown on the specification plate. Double
insulation of the tool provides protection equivalent to a
properly grounded three-conductor cord.
