S1000 Autopilot Installation Guide
33
Suppression Ferrites
The following illustration shows typical cable suppression ferrites used with Raymarine equipment. Always use the
ferrites supplied by Raymarine.
Connections to Other Equipment
If your Raymarine equipment is to be connected to other equipment using a cable not supplied by Raymarine, a
suppression ferrite MUST always be attached to the cable near the Raymarine unit.
D3548-6
