S1000 Autopilot Installation Guide
19
1.
3.
2.
1.
2.
D7683-1
3.
4.
Mark holes for the fixing screws.
Drill three 1/8" (3.4 mm) pilot
holes for the fixing screws.
Fitting S100 Remote cradle
Secure the cradle.
At fixed position
On belt clip
Countersink the pilot holes to
prevent damage to the mounting
surface.
To separate cradle from clip
Cli
ck
