Bleed procedure, sheet 4
8.
Turn the autopilot pump bleed screw, fully clockwise, and hand-tighten it.
7.
Top up the hydraulic fluid.
9.
Replace the helm pump breather cap.
D7486-1
This completes the
bleed procedure.
Now secure the pump.
Correct fluid level
Helm pump
