9
3. Plug the supplied long modular cord
(or the short cord for a wall plate) in-
to the phone jack on the back of the
phone.
4. Insert the supplied AC adapter’s
barrel plug into the DC 9V jack.
5. If you are mounting the phone on a
wall plate, route the adapter cord as
shown. Plug the modular cord into
the wall plate jack, then align the
phone’s keyhole slots with the wall
plate studs and slide the phone
downward to secure it.
Phone
Jack
DC 9V
Jack
If you are mounting the phone on a
wall, route the adapter and modular
cords as shown. Align the phone’s
keyhole slots with the screws and
slide the phone downward to secure
it, then plug the modular cord into a
modular phone line jack.
6. Plug the adapter into a standard AC
outlet.
