1. Do not smoke when spraying paint,
insecticides, or other flammable sub-
stances.
2. Use a face mask/respira-
tor when spraying and
spray in a well ventilated
area to prevent health and
fire hazards.
3. Do not direct paint or other sprayed
material at the compressor. Locate
compressor as far away from the
spraying area as possible to minimize
overspray accumulation on the com-
pressor.
4. When spraying or cleaning with sol-
vents or toxic chemicals, follow the
instructions provided by the chemical
manufacturer.
Fr 20 5
Spraying Precautions
Do not spray flammable
materials in vicinity of
open flame or near ignition
sources including the
compressor unit.
! WARNING:
Breathable Air Warning
This compressor/pump is not equipped and should not be used “as
is” to supply breathing quality air. For any application of air for
human consumption, the air compressor/pump will need to be fitted
with suitable in-line safety and alarm equipment. This additional
equipment is necessary to properly filter and purify the air to meet
minimal specifications for Grade D breathing as described in
Compressed Gas Association Commodity Specification G 7.1 - 1966,
OSHA 29 CFR 1910. 134, and/or Canadian Standards Associations
(CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used for the purpose of breathing air
application and proper in-line safety and alarm equipment is not
simultaneously used, existing warranties shall be voided, and
Campbell Hausfeld disclaims any liability whatsoever for any loss,
personal injury or damage.
! DANGER:
Pièces de rechange
Pour les pièces de rechange, appeler le 1-800-4-RIDGID
S’il vous plaît fournir l’information suivante :
-Numéro du modèle
-Numéro de série (si applicable)
-Description de la pièce et son numéro sur la liste de pièces
Safety Instructions (continued)
No de No de Numéro
clé catalogue de pièce Description Qte
1 -- FP250000AV Moteur 1
2 28258 FP250001AV Assemblage du réservoir 1
3 -- -- Arceau de sécurité 1
4 17913 D-1403 Robinet de purge 1
5 -- -- Manche 1
6 17773 GA016901AV Manomètre de réservoir 1
7 17878 GA016900AV Manomètre de refoulement 1
8 25023 WL022500AV Collecteur 1
9 28278 FP250005AV Coupleur à branchement rapide 2
10 28273 FP250004AV Soupape de sûreté 1
11 † † Vis torx creuse 4
12 † † Vis torx creuse 4
13 † † Rondelle 4
14 † † Écrou 4
15 -- -- Panneau 1
16 † † Boulon 4
17 -- -- Bouchon 2
18 † † Rondelle 4
19 † † Écrou 4
20 28298 FP250009AV Pied d’isolement 4
21 † † Rondelle 4
22 † † Vis 4
23 28263 FP250002AV Manostat (LEFOO 724-931 kPa) 1
24 † † Bouchon 1/4 po NPT 2
25 -- -- Anneau 2
26 28183 FP250006AV Cordon d’alimentation (3 fils) 1
27 28353 FP250020AV Raccord coudé 6,4 mm 90° 2
28 ▲ ▲ Garniture de tube 2
29 ▲ ▲ Virole 2
30 ▲ ▲ Écrou 2
31 -- -- Tube 1
32 ▲ ▲ Tube 1
33 28293 FP250008AV Soupape de retenue 1
34 ■ ■ Garniture de tube 2
35 ■ ■ Virole 2
36 ■ ■ Écrou 2
37 ■ ■ Tube 1
38 -- -- Raccord coudé 6,4 mm 90° 1
† = Article normal de quincaillerie -- = Pas disponible
TROUSSES DE PIÈCES DE RÉPARATION
▲ 28268 FP250003AV Kit de conduit de ventilation
■ 28288 FP250007AV Trousse de soupape de décharge
