Replacing the DC Car Adapter Fuse .............................. 35
Specifications ..................................................................... 36
PREPARATION
CONNECTING AN ANTENNA
Caution: To prevent damage to your walkie-talkie, you must
connect an antenna before you operate the walkie-talkie.
Your walkie-talkie comes with a helical antenna that is ideal for
most applications. However, the walkie-talkie’s BNC antenna
connector makes it easy to connect other types of antennas.
Your local Radio Shack store sells a wide variety of antennas.
Choose the one that best meets your needs.
Follow these steps to connect an antenna.
1. Position the BNC antenna connector over the antenna jack
on the walkie-talkie.
2. Slip the slot in the antenna connector over the antenna
jack’s tab on top of the walkie-talkie.
