Page 34
34
This device complies with Part 15 of
FCC Rules
. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, includ-
ing interference that may cause undesired operation.
REPLACING THE DC
CAR ADAPTER FUSE
The DC car adapter has a 32V 2-amp fuse in the cigarette lighter
plug. When replacement is required, use a slow-blow glass fuse,
such as Cat. No. 270-1023.
1. Turn the cap on the adapter plug counterclockwise to un-
screw it from the plug body.
2. Remove the old fuse and inspect its condition. If it is
“blown” and requires replacement, insert a new 2-amp
fuse. If it is not “blown,” reinsert it.
3. Replace the spring, the terminal, and the cap and screw
the cap in tightly.
