8
FEATURES
KNOW YOUR DRILL
See Figure 1.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
BIT STORAGE
Bits provided with the drill can be plac ed in the storage area,
located on the base of the drill.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
Your drill has a direction of rotation (forward/reverse/center
lock) selector located above the switch trigger for changing
the direction of bit rotation. Setting the switch trigger in the
OFF (center lock) position helps reduce the possibility of
accidental starting when not in use.
KEYLESS CHUCK
The keyless chuck allows you to hand-tighten or release the
drill bit in the chuck jaws.
LED WORKLIGHT
The LED worklight, located under the chuck, illuminates
when the switch trigger is depressed. This provides extra
light for increased visibility.
TORQUE ADJUSTMENT RING
Your drill has a 4-position clutch. The torque adjustment
ring can be turned to select the right amount of torque for
your application.
TWO-SPEED GEAR TRAIN
The two-speed gear train is designed for drilling or driving
at
LO (1) or HI (2) speeds. A slide switch is located on top
of your drill for selecting either LO (1) or HI (2) speed.
VARIABLE SPEED
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
UNPACKING
This product has been shipped completely assembled.

Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
 Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
 Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
 If any parts are damaged or missing, please call
-866-539-70 for assistance.
PACKING LIST
Drill
Double-ended Bit
Tool Bag
Operator's Manual
ASSEMBLY
WARNING:
If any parts are damaged or missing do not operate
this product until the parts are replaced. Failure to
heed this warning could result in serious personal
injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING:
To prevent accidental starting that could cause
serious personal injury, always remove the battery
pack from the product when assembling parts.
WARNING:
To reduce of risk of fire, burn, explosion or injury,
user must read and understand operator’s manual.
Wear eye protection.
