Section 1 Configuration

1

UTION

CA

Use an IC149-064-075-B51 socket (manufactured by

YAMAICHI ELECTRONICS Co., Ltd.) for the FP-64E
package IC socket on the user system.

Figure 1 shows the configuration of the HS3627ECN61H user system interface cable for the
FP-64E package.
