5. External Dimensions

75.0

20

.0

M34559T-PTCB REV.A

MADE IN JAPAN

45

.0

25

.5

Figure 3 External dimensions of the M34559T-PTCB

6. Precautions

CAUTION

Caution to Be Taken for This Product:

z When connecting the YQPACK052SB, be sure to use the included YQ-GUIDE’s.
z Do NOT use the screws included with the YQPACK052SB for connecting the YQPACK052SB.

IMPORTANT

Notes on This Product:

z We cannot accept any request for repair.
z For purchasing the NQPACK052SB, YQPACK052SB, HQPACK052SB, contact the following:

Tokyo Eletech Corporation

http://www.tetc.co.jp/e_tet.htm

z For inquiries about the product or the contents of this manual, contact your local distributor.

Renesas Tools Homepage

http://www.renesas.com/tools
