Specifications

Specifications

Amplifier Section

Output Power (6 ohms, 40 Hz ~ 20 kHz, 0.9% T.H.D) : Stereo .......................................................................................... Front L/R (2 Channel Driven)100W x 2ch

Output Power (6 ohms, 1 kHz, 0.9% T.H.D)

Front L/R (2 Channel Driven) ................................................................................................................................................................................... 100 W x 2ch
Center (1 Channel Driven) ....................................................................................................................................................................................... 100 W x 1ch
Rear L/R (2 Channel Driven).................................................................................................................................................................................... 100 W x 2ch
Subwoofer (1 Channel Driven) ................................................................................................................................................................................. 100 W x 1ch

Distortion at 1 kHz, 100 W

Front L/R .......................................................................................................................................................................................................................... < 0.9%
Center/Subwoofer ............................................................................................................................................................................................................ < 0.9%
Rear L/R ........................................................................................................................................................................................................................... < 0.9%

S/N Ratio (IHF-A Weighted)

S/N Ratio (IHF-A Weighted, -20dB FS)

SURROUND Front .......................................................................................................................................................................................................... > 65 dB
SURROUND Center........................................................................................................................................................................................................ > 65 dB
SURROUND Rear........................................................................................................................................................................................................... > 65 dB

Frequency Response

Front L/R .............................................................................................................................................................................................. 10 - 20 kHz, -3 dB/+1 dB
Center (Large) ...................................................................................................................................................................................... 10 - 20 kHz, -3 dB/+1 dB
Rear L/R ............................................................................................................................................................................................... 10 - 20 kHz, -3 dB/+1 dB
Subwoofer ....................................................................................................................................................................................................... 10 - 120 Hz, -3 dB

Tone Control

Bass (100 Hz) ................................................................................................................................................................................................................. +/-10 dB
Treble (10 kHz)................................................................................................................................................................................................................ +/-10 dB

Input Sensitivity

STEREO-TV (Line) ......................................................................................................................................................................................................... 320 mV
Video (Monitor Output) ......................................................................................................................................................................................... 1 Vpp/75 ohm

Output Level

Audio (Tape REC OUT)....................................................................................................................................................................................... 280 mV/1 kohm
Video (Monitor Out) .............................................................................................................................................................................................. 1 Vpp/75 ohm

Cross-Talk (Separation)

STEREO-TV (Line) ......................................................................................................................................................................................................... > 55 dB
Dolby Digital .................................................................................................................................................................................................................... > 45 dB

Delay Time

Dolby Pro Logic ............................................................................................................................................................................................ Rear: 15 - 30 msec.
Dolby Digital ................................................................................................................................................................................................... Rear: 0 - 15 msec.

Center : 0 - 5 msec.

Tuner Section

(FM) Frequency Range ............................................................................................................................................................................................... 87.5 - 108 MHz

(FM) Sensitivity

Mono (THD 3%) .................................................................................................................................................................................................... 15 uV/m, EMF

(FM) Distortion (15 kHz LPF on)

Mono ................................................................................................................................................................................................................................ < 0.4%
Stereo............................................................................................................................................................................................................................... < 0.5%

(FM) S/N Ratio

Mono ............................................................................................................................................................................................................................... > 68 dB
Stereo.............................................................................................................................................................................................................................. > 63 dB

(FM) Frequency Response...................................................................................................................................................................................... 20 - 15 kHz, -3 dB

(AM) Frequency Range ............................................................................................................................................................................................... 520 - 1710 kHz

(AM) Sensitivity ( Loop Antenna).......................................................................................................................................................................................... 600 uV/m

(AM) Selectivity, +/- 10K .......................................................................................................................................................................................................... > 25 dB

(AM) S/N Ratio ........................................................................................................................................................................................................................ > 40 dB

Video Section

Output Level .......................................................................................................................................................................................................... 1.0 V (p-p), 75 ohm
