Chapter 6 – Configuring Rapid Spanning Tree
RSTP Configuration
Bridge and Port Parameter Ranges & Default Settings
The following set of tables lists default STP configuration parameters for the unit.
For each parameter the parameter name, recommended setting and possible range
are included.
Bridge Parameters
Configuration Item
Default Value
Supported Values
State Enabled Disabled,
Enabled
Version Support
STP and RSTP
STP, STP and RSTP
Hello Time
2 seconds
1 to 10 seconds
Max Age Time
20 seconds
6 to 40 seconds
Transmit Count
10
3 to 10
Forward Delay
15 seconds
4 to 30
Cost Style
Costs follow STP (16 bit) style
Costs follow STP (16 bit) style, Costs follow
RSTP (32 bit) style
Port Parameters
These configurable items apply to all ports.
Configuration Item
Default Value
Supported Values
Enabled
Port Enabled
Disabled, Enabled
Priority
128
0, 16, 32, 48, 64, 80, 96, 112, 128, 144, 160,
176, 194, 208, 224, 240
STP Cost
Auto
Auto, 0 to 65535
RSTP Cost
Auto
Auto, 0 to 2147483647
Edge Port
False
False, True
Point to Point
Auto
Auto, False, True
